06 CBR600RR Fairing Compatibility with Other Honda Models

NiceFairings.com

·August 17, 2025

·12 min read

You can swap 06 cbr600rr fairings directly with 05-06 cbr600rr models. Some parts also fit the 2003-2004 cbr600rr, but you may need to modify certain fairings. Always check the model year, subframe, and air ducts before starting. Regional differences can affect compatibility. Careful planning helps you avoid issues and ensures your new fairings fit well.

06 CBR600RR Fairings Compatibility Overview

Direct Fit Honda Models

You can install 06 cbr600rr fairings directly onto 05-06 cbr600rr models. The mounting points, subframe, and air ducts match perfectly. You do not need to make any changes or adjustments. This direct fit saves you time and effort. You get a seamless look and factory-level compatibility. Many riders choose this option for quick upgrades or repairs.

Models Requiring Modifications

You may want to fit 06 cbr600rr fairings onto older cbr600rr models, such as the 2003-2004 versions. These models require some minor changes. You can complete these modifications with basic tools and a little patience. Most users describe the process as easy. Here are the typical steps you need to follow:

Change the windscreen and ram air tubes for proper fit.
Drill the tail section to mount the seat securely.
Consider swapping the subframe if the mounting points do not align.
Check all connections before final installation.

Tip: Always test-fit each piece before making permanent changes. This step helps you avoid mistakes and ensures the best compatibility.

Compatibility Chart for cbr600rr Fairings

You can use the following chart to check which models accept 06 cbr600rr fairings and what modifications you need:

Honda Model Year	Direct Fit	Modifications Needed	Notes
2003-2004	❌	✅	Change windscreen, ram air tubes, drill tail, possible subframe swap
2005-2006	✅	❌	Full compatibility with 06 cbr600rr fairings
2007+	❌	❌	Major differences; not recommended

You should always check the specific details for your bike. Compatibility depends on the year and model. You can avoid problems by planning ahead and confirming fitment.

Fairing Parts Breakdown for cbr600rr

Front Fairing Compatibility

You will notice that the front fairing plays a key role in the overall look and function of your bike. When you swap the front fairing from a 2006 cbr600rr, you get a direct fit for the 2005-2006 models. The mounting holes and headlight brackets line up perfectly. You do not need to adjust the subframe or change the headlight assembly. If you try to install this fairing on a 2003-2004 model, you must check the windscreen and ram air tube fitment. Some riders report that the older models need minor drilling or trimming for a secure fit.

Tip: Always inspect the tabs and clips before installation. Damaged tabs can cause rattling or loose panels.

Side Fairing Compatibility

The side fairings protect your engine and give your bike a sleek profile. You can swap side fairings between 2005 and 2006 cbr600rr models without any issues. The bolt pattern matches, and the lower edge lines up with the belly pan. For 2003-2004 models, you may need to adjust the mounting points. Some users recommend using spacers or washers to achieve a flush fit. You should also check the compatibility of the air ducts, as the design changed slightly in later years.

Model Year	Direct Side Fairing Fit	Notes
2003-2004	❌	May need spacers, check air duct fit
2005-2006	✅	No modifications needed

Tail Fairing Compatibility

The tail fairing covers the rear subframe and supports the seat. You can install a 2006 tail fairing on a 2005 model with no extra work. The seat latch and mounting bolts match up. For 2003-2004 cbr600rr bikes, you must drill new holes or swap the subframe for proper alignment. Some riders choose to upgrade the seat at the same time for a better fit. Always test the seat lock and tail light connections before finishing the job.

Note: If you use aftermarket fairings, check the thickness and finish. Some aftermarket parts may need extra trimming for a clean look.

Lower Fairing Compatibility

You need to check the lower fairing before swapping parts. The lower fairing sits under the engine and connects both side fairings. On 2005 and 2006 models, you can swap the lower fairing without any issues. The mounting holes and shape match perfectly. You do not need to trim or drill anything. This makes the process fast and simple.

If you want to use a 2006 lower fairing on a 2003 or 2004 model, you may face some challenges. The mounting points on older frames do not always line up. You might need to drill new holes or use custom brackets. Some riders use zip ties as a temporary fix, but this does not look professional. Always check the fit before you finish the installation.

Note: The lower fairing protects your engine from road debris and helps with airflow. Make sure it fits tightly to avoid rattling or damage.

Here is a quick checklist for lower fairing swaps:

Inspect all mounting tabs and holes.
Test-fit the lower fairing before final installation.
Use proper hardware for a secure fit.
Avoid forcing panels into place.

Inner Panels and Air Ducts

Inner panels and air ducts play a big role in cooling and airflow. On 2005 and 2006 models, you can swap these parts easily. The design and fit match well. You do not need to make changes. On 2003 and 2004 models, the air ducts may not align with the frame or airbox. You may need to trim the ducts or use adapters.

You should always check the condition of the inner panels. Cracked or warped panels can cause poor airflow. This can lead to overheating. Replace damaged parts before you install new fairings.

Model Year	Inner Panel Fit	Air Duct Fit	Notes
2003-2004	❌	❌	May need trimming or adapters
2005-2006	✅	✅	Direct fit, no changes needed

Tip: Clean the air ducts and panels before installation. Dirt and debris can block airflow and reduce performance.

You can keep your cbr600rr running cool and looking sharp by checking these details.

Year-to-Year Differences in 06 cbr600rr Fairings

2005 vs. 2006 cbr600rr

You will find almost no difference in fairing fitment between the 2005 and 2006 models. Honda kept the mounting points, subframe, and air ducts the same for both years. You can swap upper, mid, and lower fairings between these models without any modification. The only changes you will notice are in the color schemes and decals. This makes 05-06 cbr600rr fairings highly interchangeable. You do not need to worry about structural changes or new mounting hardware. If you want a quick upgrade or replacement, you can choose either year’s fairings with full confidence in compatibility.

Tip: Always check the color codes if you want a perfect match for your bike.

2003-2004 cbr600rr Models

Honda designed the 2003-2004 cbr600rr with a different style and frame. You will see larger, rounder fairings inspired by MotoGP. These models use conventional front forks and axial-mounted brake calipers. The frame uses Hollow Fine Die Cast aluminum, which makes it lighter but changes the mounting points. You cannot swap 06 cbr600rr fairings onto these models without making adjustments. You may need to drill new holes, trim panels, or swap the subframe. The air ducts and tail section also require modification. You should plan for extra work if you want to fit newer fairings on these older bikes.

Key Differences Table

Feature	2003-2004 Models	05-06 cbr600rr Models
Fork Type	Conventional	Inverted (USD)
Brake Calipers	Axial-mounted	Radial-mounted
Frame Design	Hollow Fine Die Cast	New lighter aluminum
Fairing Style	Larger, rounder	Compact, sharp-edged
Mounting Points	Different	Identical (05-06)

2007+ cbr600rr and Other Honda Sportbikes

Honda introduced major changes to the cbr600rr in 2007 and later years. You will see a new frame, redesigned fairings, and updated electronics. The mounting points and bodywork changed completely. You cannot use 06 cbr600rr fairings on these models. The compatibility drops to zero for direct swaps. Other Honda sportbikes, such as the CBR1000RR, also use different fairing shapes and mounting systems. If you want to upgrade or repair your bike, you should always check the year and model before buying fairings.

Note: You can avoid costly mistakes by confirming fitment with your dealer or trusted parts supplier.

Modifications and Installation for 06 cbr600rr Fairings

Required Modifications for Non-Direct Fits

When you install 06 cbr600rr fairings on models outside the 2005-2006 range, you often need to make small changes. You might need to drill new holes in the tail section or adjust the fit of the side panels. Sometimes, you must trim the air ducts or use spacers to line up the mounting points. Always test-fit each piece before you secure it. This step helps you spot any issues early.

Tip: Use masking tape to mark drilling spots. This method helps you avoid mistakes and keeps your fairings looking clean.

Subframe and Mounting Points

The subframe supports the fairings and connects them to your bike. If you swap fairings onto a 2003-2004 model, you may find that the mounting points do not match. You can solve this by swapping to a compatible subframe or by using custom brackets. Check all bolt holes and tabs before you start. A secure fit prevents rattling and keeps your fairings safe at high speeds.

Inspect the subframe for cracks or bends.
Align each mounting point before tightening bolts.
Use factory hardware when possible for the best fit.

Electrical and Lighting Considerations

When you swap fairings, you must also check the headlight and wiring setup. The 2006 CBR600RR uses H7 bulbs with a single filament per lens. Other Honda models, like the 2008 CBR600RR, use H4 bulbs with dual filaments. This difference means you need to adapt the wiring harness and possibly change the bulb type. If you skip this step, your headlights may not work correctly.

Here is a quick comparison:

Aspect	2006 CBR600RR	2008 CBR600RR	What You Need to Do
Bulb Type	H7, single filament	H4, dual filament	Adapt wiring and bulb type
Headlight Setup	Left: low, Right: high beam	Both: low/high beam	Change wiring for correct function
Reflector and Housing	For single filament bulbs	For dual filament bulbs	Adjust for beam direction
Wiring Harness	H7 bulb wiring	H4 bulb wiring	Modify harness as needed

Note: Many forums recommend against using resistors. Instead, adapt the wiring for a safe and reliable setup.

You keep your bike safe and street-legal when you handle these electrical details.

Exceptions and Special Considerations for cbr600rr

California vs. 49-State Fairings

You may notice differences between California and 49-state models. California bikes often have extra emissions equipment. This equipment can change the shape or mounting points of some panels. When you install new fairings, check for extra cutouts or tabs near the charcoal canister or emissions hoses. Some aftermarket kits do not include these features. You might need to trim or modify panels for a proper fit on California bikes. Always compare your old panels to the new ones before starting the installation.

Note: California-specific fairings sometimes cost more and may be harder to find. Double-check part numbers when ordering replacements.

ABS and Non-ABS Model Differences

Honda offered ABS on some CBR600RR models. ABS versions use different brake lines and sometimes have extra sensors or brackets. These changes can affect how the fairings fit around the lower front and near the wheels. If your bike has ABS, look for fairings with extra clearance or pre-cut holes for sensors. Non-ABS models do not need these features. You should always check your bike’s brake setup before buying new panels.

Feature	ABS Model Needs	Non-ABS Model Needs
Brake Line Space	Extra clearance needed	Standard clearance
Sensor Holes	May require cutouts	Not required
Panel Fit	Check for interference	Direct fit

Aftermarket vs. OEM 06 cbr600rr Fairings

You have many choices when replacing your fairings. OEM panels set the standard for fit and finish. They use high-quality materials and match the original paint. Aftermarket brands like Motofans and Auctmarts often come very close to OEM fitment, with many riders rating them 9 or 10 out of 10. These brands use injection molding for better accuracy and strength. Some cheaper aftermarket kits, especially those made for California models, may not fit as well. Paint quality can also vary, and colors may not match the factory exactly. Many aftermarket suppliers offer warranties and replacement policies, which can give you peace of mind.

Injection-molded aftermarket fairings usually fit well and feel sturdy.
Cheaper kits may need extra trimming or adjustment.
OEM panels remain the best choice for perfect fit and original paint.

Tip: Always test-fit aftermarket panels before painting or final installation. This step helps you avoid surprises and ensures a clean result.

Practical Advice for Swapping 06 cbr600rr Fairings

Sourcing Compatible Fairings

You want fairings that fit well and last long. Many riders choose alFairings for their 2006 CBR600RR. This supplier uses high-grade virgin ABS plastic and injection molding. You get fairings that match the original shape and strength. The price is about one-fifth of OEM fairings, so you save money. You can pick street fairings with pre-cut holes or race fairings for track use. Custom paint and decals are available if you want a unique look. Each set includes 20 pieces, such as painted cowls, a windscreen, a tank pad, a heat shield, and hardware. You also get a 180-day free return policy and free shipping.

Popular sources for 06 CBR600RR fairings:

alFairings (aftermarket, high-quality ABS, custom options)
OEM Honda dealers (original fit and paint)
Motorcycle forums and classifieds (used or rare parts)

Tip: Always check the return policy and warranty before you buy.

Tools and Preparation for Installation

You need the right tools to install fairings safely and quickly. Professional mechanics recommend a metric socket set with sizes like 32mm, 30mm, and 22mm. Use two torque wrenches—one large for axle nuts and one small for other bolts—to avoid over-tightening. T-handle Allen wrenches make the job easier. Keep pliers and a Phillips head screwdriver handy. Use front and rear stands to keep your bike stable. Apply blue Loctite to bolts for extra security. A Motion Pro front axle holder helps with the front axle. A tape measure and wire cutters also come in handy.

Essential tools checklist:

Metric socket set (32mm, 30mm, 22mm)
Two torque wrenches
T-handle Allen wrenches
Pliers and Phillips screwdriver
Front and rear stands
Blue Loctite
Motion Pro front axle holder
Tape measure and wire cutters

Note: Organize your tools before you start. This step saves time and prevents mistakes.

Common Mistakes to Avoid

Many riders rush the process and make simple errors. You should always test-fit each fairing piece before final installation. Do not force panels into place. If a part does not fit, check the mounting points and hardware. Skipping the use of torque wrenches can strip bolts or damage threads. Forgetting to use Loctite may cause bolts to loosen over time. Some riders ignore the differences between ABS and non-ABS models or overlook special cutouts for California bikes. Always compare your old fairings to the new ones before drilling or trimming.

Mistake	How to Avoid
Skipping test-fit	Dry-fit all panels first
Over-tightening bolts	Use torque wrenches
Ignoring model details	Check ABS, emissions, and year
Not using Loctite	Apply blue Loctite to all bolts

🛠️ Careful planning and the right tools help you achieve a professional result.

You can fit 06 cbr600rr fairings directly on 2005 and 2006 models. Older models, like 2003 and 2004, need some modifications. Always check fitment details before you buy or install new fairings. Monster Fairings and alFairings offer injection-molded ABS fairings with strong durability and precise fitment, making them smart alternatives to OEM parts. When you choose fairings, consider these factors:

Material and heat resistance
Craftsmanship and fitment
Paint finish and decals
Cost and design preference

Careful selection helps you achieve a professional look and long-lasting performance.

FAQ

Can you use 06 CBR600RR fairings on a 2007 or newer CBR600RR?

You cannot use 2006 fairings on 2007 or newer models. Honda changed the frame and mounting points in 2007. The panels will not fit or align correctly.

Do aftermarket fairings fit as well as OEM fairings?

High-quality aftermarket fairings, like those from alFairings, often fit very well. You may need minor adjustments. OEM fairings always provide the best fit and finish.

What should you check before buying used fairings?

Always inspect for cracks, missing tabs, and paint damage. Ask for clear photos. Confirm the fairings match your bike’s year and model. This step helps you avoid costly mistakes.

Will fairings from a California model fit a 49-state bike?

Most panels fit both versions, but California models may have extra cutouts for emissions equipment. You might need to trim or modify some panels for a perfect fit.

Do you need special tools to install 06 CBR600RR fairings?

You need basic hand tools, a metric socket set, and Allen wrenches. Use a torque wrench for bolts. Front and rear stands help keep your bike stable during installation.
